Advatek - PixLite R1F-S Receiver - Single Output

Advatek - PixLite R1F-S Receiver - Single Output

€89,00 EUR
€89,00 EUR €89,00 EUR
Sale Sold out
Shipping calculated at checkout.

Price Excluding VAT

Meet the PixLite® R1F-S, Advatek’s newest long-range receiver, designed to be used with the PixLite® T16X-S. Focusing on flexibility and cost optimization.​ The R1F-S offers a 5-48V compatibility, higher current capacity, and a compact design perfect for tight spaces.

  • Single pixel output
  • Slimline form factor
  • Receiver and pixels can be driven at 5-48V
  • 10A throughput current
  • Multiple receivers cover a 300-meter radius from the transmitter
  • Ideal for installations requiring a sleek, low-profile unit
  • DIN rail mount
  • Flat surface mount
  • Tubular surface mount
  • Global certifications
  • Conformal Coating: apply a protective layer to your electronic equipment to enhance durability

Technical Details

  • Pixel Outputs - 1 x Powered
  • Data Inputs (From Transmitter) - 1
  • Dimensions - 72 x 39 x 31mm
  • Weight - 0.054kg
  • Enclosure Material - Black Polycarbonate
  • Mounting Options - Flat/Tubular Surface & Din-Rail Mountable
  • Input Power - 5V - 48V DC
  • Per Output Current Limit - 10A
  • Ambient Operating Temperature - -20°C to +55°C
  • Country of Origin - Australia

Documentation
